RCF NX 932-A

RCF NX 932-A

RCF NX 932-A PROFESSIONAL ACTIVE SPEAKER

FEATURES

  • Up to 132 dB Sound Pressure Level
  • 2100W Class-D Bi-Amplification
  • 45-20000 Hz linear frequency response
  • 3" Titanium/Neodymium Compression Driver
  • 12" Woofer
  • FiRPHASE zero degrees phase technology
  • Bass Motion Control woofer excursion management
  • Six M10 and four Quick Lock rigging points

RCF NX 932-A is masterfully engineered from the ground up to deliver stellar audio performance for sound providers, small bands and DJs. The combination of a 3" titanium/neodymium compression driver, 12" woofer - two-channel 2,100W amplifier, and the constant directivity True Resistive Waveguide produces coherent 100° x 70° coverage for the listening area with up to 132 dB SPL, distortion-free sound. Used as a stand-alone speaker for a FOH system, satellite (with subwoofer), stage monitor, or flown speaker, the NX 932-A blends high performance and reliability in a compact package. Merging RCF proprietary FiRPHASE and Bass Motion Control DSP processing, perfectly tuned for each model, the audience will experience absolute sound clarity and deep, powerful bass response. The tour-ready, rugged all-wood cabinet is easy to carry and secure to install on a pole-, flown-, wall-, or truss-mounted using the dedicated rigging points available.

ACOUSTICAL SPECIFICATIONS
Frequency Response
45 Hz ÷ 20000 Hz
Max SPL @ 1m
132 dB
Horizontal coverage angle
100°
Vertical coverage angle
70°
TRANSDUCERS
Compression Driver
1 x 1.4'' neo, 3.0'' v.c
Woofer
1 x 12'', 2.5'' v.c
INPUT/OUTPUT SECTION
Input signal
bal/unbal
Input connectors
Combo XLR/Jack
Output connectors
XLR
Input sensitivity
-2 dBu/+4 dBu
PROCESSOR SECTION
Crossover Frequencies
700Hz
Protections
Thermal, RMS
Limiter
Soft Limiter
Controls
Linear, Boost, Stage, Volume
POWER SECTION
Total Power
2100 W Peak
High frequencies
700 W Peak
Low frequencies
1400 W Peak
Cooling
Convection
Connections
Powercon TRUE1 TOP IN/OUT
STANDARD COMPLIANCE
Safety agency
CE compliant
PHYSICAL SPECIFICATIONS
Cabinet/Case Material
Plywood
Hardware
2 x M10 Top, 1 x M10 each side, 1 x M10 bottom, 1 x M10 rear
2 each side quick lock pin seat
Handles
1 x Side
Pole mount/Cap
35 mm insert
Grille
Steel
Color
Black, White
SIZE / WEIGHT
Height
620 mm / 24.41 inches
Width
362 mm / 14.25 inches
Depth
405 mm / 15.94 inches
Weight
22.9 kg / 50.49 lbs
SHIPPING INFORMATION
Package Height
666 mm / 26.22 inches
Package Width
461 mm / 18.15 inches
Package Depth
416 mm / 16.38 inches
Package Weight
26 kg / 57.32 lbs
$549.58

Original: $1,570.24

-65%
RCF NX 932-A

$1,570.24

$549.58
