Eurolite 6 channel DMX Dimmer Panel

Eurolite 6 channel DMX Dimmer Panel

EUROLITE 6 channel FD-6+1 DMX Dimmer Panel. Simple DMX controller for 6 channels with master controller

• Simple DMX controller for convenient control of light effect devices with DMX512 interface (e.g. spotlights and dimmers)
• 6 channel faders for setting the DMX value
• 1 master fader
• Compact design
• 3-pin XLR connector
• Power supply via supplied power supply unit or 9 V block (not incl.)
• Can send up to 6 DMX channels
• Controllable via DMX
• Desk desk housing

Power supply:	100-240 V AC, 50/60 Hz 9 V DC
Total connected load:	1.8 W
Protection class:	IP20
Protection class:	SK III
Power connection:	Power supply barrel connector (M) built-in version power connection cable with plug-in power supply unit (included)
Battery:	1 x 9.0 V E block
DMX channels:	Issue 6
DMX output:	1 x 3-pin XLR (F) built-in version
Control:	DMX
Housing color:	black
Colour:	black
Housing design:	Desk desk housing
Dimensions:	Width: 17 cm Depth: 15.5 cm Height: 6 cm
