Eurolite DMX LED EASY Operator 4x4

Eurolite DMX LED EASY Operator A small yet versatile DMX PAR can controller for 3, 4, 5 and 6-colour fixtures. Six channel faders can be configured to 6 different arrangements of R, G, B, W, A, V and dimmer control. Furthermore, a mix fader enables smooth manual scrolling of colours. Features sound activated option with sensitivity control or auto mode with 8 MAC programs and speed control offer a choice of sequences with additional manual strobe and blackout functions. Free standing or wall-mounted operation for comprehensive control over stage lighting or architectural installations.

• Compact DMX controller for 4 LED spotlights with up to 4 colors each

  • DMX controller for standard LED spotlights
  • Easy handling
  • 4 fixtures with RGBW LEDs can be controlled individually or in combination
  • DMX channels for red, green, blue, white and master
  • Various modes for the DMX channel sequence selectable
  • Manual control via 4 faders
  • 1 fader for direct RGBW mixing
  • Adjustable strobe function
  • Blackout function
  • 8 integrated show programs
  • Can transmit up to 20 DMX channels
  • Control via DMX; Sound to light via Microphone; stand-alone
  • Desktop console housing

  Package contents

  • 1 x controller, 1 x external mains adapter, 1 x user manual

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz 9 V DC 800 mA
Power consumption:	10 W
IP classification:	IP20
Protection class:	Protection class III
Power connection:	Mains input via Coaxial power connector (M) mounting version power supply cord with AC adapter (provided)
DMX channels:	Output 20
DMX output:	1 x 3-pin XLR (F) mounting version
Control:	DMX; Sound to light via Microphone; stand-alone
Housing color:	Black
Color:	Black
Housing design:	Desktop console housing
Dimensions:	Width: 20 cm Depth: 11,5 cm Height: 5,5 cm
Weight:	860 g
