RCF NX 912-A
RCF NX 912-A PROFESSIONAL ACTIVE SPEAKER
FEATURES
- Up to 130 dB Sound Pressure Level
- 2100W Class-D Bi-Amplification
- 50-20000 Hz linear frequency response
- 1.75" Compression Driver
- 12" Woofer
- FiRPHASE zero degrees phase technology
- Bass Motion Control woofer excursion management
RCF NX 912-A is masterfully engineered from the ground up to deliver stellar audio performance for solo musicians, bands, and DJs. The combination of 1.75" compression driver, 12" woofer, two-channel 2100W amplifier, and a constant directivity waveguide produces coherent 100° x 60° coverage for the listening area with up to 130 dB SPL of distortion-free sound.
Used stand-alone speaker for a FOH system, satellite (with subwoofer), stage monitor, or flown speaker, the NX 912-A blends high-performance and reliability in a compact package. Blending RCF proprietary FiRPHASE and Bass Motion Control DSP processing, NX 9 Series speakers are perfectly tuned for each model, delivering absolute clarity and deep, powerful bass response.
The tour-ready, rugged all-wood cabinet is easy to carry and secure to install on a pole-, flown-, wall-, or truss-mounted using the dedicated rigging points available.
| Category | Specification |
|---|---|
| Acoustical Specifications | |
| Frequency Response | 50 Hz ÷ 20000 Hz |
| Max SPL @ 1m | 130 dB |
| Horizontal Coverage Angle | 100° |
| Vertical Coverage Angle | 60° |
| Transducers | |
| Compression Driver | 1 x 1.0'', 1.75'' v.c |
| Woofer | 1 x 12'', 2.5'' v.c |
| Input/Output Section | |
| Input Signal | bal/unbal |
| Input Connectors | XLR, Jack |
| Output Connectors | XLR |
| Input Sensitivity | -2 dBu/+4 dBu |
| Processor Section | |
| Crossover Frequencies | 1600 Hz |
| Protections | Thermal, RMS |
| Limiter | Soft Limiter |
| Controls | Linear, Boost, Stage, Volume |
| Power Section | |
| Total Power | 2100 W Peak |
| High Frequencies | 700 W Peak |
| Low Frequencies | 1400 W Peak |
| Cooling | Convection |
| Connections | VDE |
| Standard Compliance | |
| Safety Agency | CE compliant |
| Physical Specifications | |
| Cabinet/Case Material | Plywood |
| Hardware | 2 x M10 Top, 1 x M10 each side, 1 x M10 bottom, 1 x M10 rear |
| Handles | 1 x Side |
| Pole Mount/Cap | 35 mm insert |
| Grille | Steel |
| Color | Black |
| Size / Weight | |
| Height | 620 mm / 24.41 inches |
| Width | 362 mm / 14.25 inches |
| Depth | 405 mm / 15.94 inches |
| Weight | 20.8 kg / 45.86 lbs |
| Shipping Information | |
| Package Height | 666 mm / 26.22 inches |
| Package Width | 461 mm / 18.15 inches |
| Package Depth | 416 mm / 16.38 inches |
| Package Weight | 22.8 kg / 50.27 lbs |
Original: $1,139.56
-65%$1,139.56
$398.85
Description
RCF NX 912-A PROFESSIONAL ACTIVE SPEAKER
FEATURES
- Up to 130 dB Sound Pressure Level
- 2100W Class-D Bi-Amplification
- 50-20000 Hz linear frequency response
- 1.75" Compression Driver
- 12" Woofer
- FiRPHASE zero degrees phase technology
- Bass Motion Control woofer excursion management
RCF NX 912-A is masterfully engineered from the ground up to deliver stellar audio performance for solo musicians, bands, and DJs. The combination of 1.75" compression driver, 12" woofer, two-channel 2100W amplifier, and a constant directivity waveguide produces coherent 100° x 60° coverage for the listening area with up to 130 dB SPL of distortion-free sound.
Used stand-alone speaker for a FOH system, satellite (with subwoofer), stage monitor, or flown speaker, the NX 912-A blends high-performance and reliability in a compact package. Blending RCF proprietary FiRPHASE and Bass Motion Control DSP processing, NX 9 Series speakers are perfectly tuned for each model, delivering absolute clarity and deep, powerful bass response.
The tour-ready, rugged all-wood cabinet is easy to carry and secure to install on a pole-, flown-, wall-, or truss-mounted using the dedicated rigging points available.
| Category | Specification |
|---|---|
| Acoustical Specifications | |
| Frequency Response | 50 Hz ÷ 20000 Hz |
| Max SPL @ 1m | 130 dB |
| Horizontal Coverage Angle | 100° |
| Vertical Coverage Angle | 60° |
| Transducers | |
| Compression Driver | 1 x 1.0'', 1.75'' v.c |
| Woofer | 1 x 12'', 2.5'' v.c |
| Input/Output Section | |
| Input Signal | bal/unbal |
| Input Connectors | XLR, Jack |
| Output Connectors | XLR |
| Input Sensitivity | -2 dBu/+4 dBu |
| Processor Section | |
| Crossover Frequencies | 1600 Hz |
| Protections | Thermal, RMS |
| Limiter | Soft Limiter |
| Controls | Linear, Boost, Stage, Volume |
| Power Section | |
| Total Power | 2100 W Peak |
| High Frequencies | 700 W Peak |
| Low Frequencies | 1400 W Peak |
| Cooling | Convection |
| Connections | VDE |
| Standard Compliance | |
| Safety Agency | CE compliant |
| Physical Specifications | |
| Cabinet/Case Material | Plywood |
| Hardware | 2 x M10 Top, 1 x M10 each side, 1 x M10 bottom, 1 x M10 rear |
| Handles | 1 x Side |
| Pole Mount/Cap | 35 mm insert |
| Grille | Steel |
| Color | Black |
| Size / Weight | |
| Height | 620 mm / 24.41 inches |
| Width | 362 mm / 14.25 inches |
| Depth | 405 mm / 15.94 inches |
| Weight | 20.8 kg / 45.86 lbs |
| Shipping Information | |
| Package Height | 666 mm / 26.22 inches |
| Package Width | 461 mm / 18.15 inches |
| Package Depth | 416 mm / 16.38 inches |
| Package Weight | 22.8 kg / 50.27 lbs |
