Arturia MiniFuse 4
Arturia MiniFuse 4
Record your song, record your story, record you - record anything. MiniFuse 4 is a next-gen 4in/4out audio & MIDI interface designed to transform your ideas into your art. Capture crystal-clear recordings, refine with pro-grade creative software, and get your sound out there.
You need great sound and a great workflow to make your creativity happen. MiniFuse 4 is an evolved audio interface designed to take you there.
For bands, producers, performers, podcasters, and everyone in between; enjoy best-in-class sound quality, an innovative feature set, and the best software included as standard. MiniFuse 4 ticks all the boxes - what’s stopping you?
MiniFuse 4’s connections, features, and unique innovations are designed to make your creative life easier.
From careful selection of components through to manufacture & testing, the MiniFuse range is engineered to last.
Each interface is constructed with the most robust & reliable materials, and goes through over 200 reliability tests before approval, meaning better build quality, a better product for the environment, and better value for you.
Unmatched Sound Quality
Line Inputs
• Input impedance: 16kΩ
• Maximum input level: +22dBu
• Gain range: 56dB
• Frequency response 20Hz to 20kHz: +/-0.05dB (min gain)
• Dynamic range: 110dB typical (A-weighted)
• THD+N @ 1kHz: -100dB typical (un-weighted)
Instrument Input
• Input impedance: 1MΩ on Tip
• Maximum input level: +11.5dBu
• Gain range: 56dB
• Frequency response 20Hz to 20kHz: +/-0.06dB (min gain)
• Dynamic range: 110dB typical (A-weighted)
• THD+N @ 1kHz: -91dB typical (un-weighted)
Microphone Preamps
• Input impedance: 2.5kΩ
• Maximum input level: +9dBu
• Gain range: 56dB
• Equivalent Input Noise (EIN): -129dB typical (A-weighted)
• Frequency response 20Hz to 20kHz: +/-0.06dB (min gain)
• Dynamic range: 110dB typical (A-weighted)
• THD+N @ 1kHz: -100dB typical (un-weighted)
Speakers
• Output impedance: 94Ω
• Maximum output level: +12dBu
• Frequency response 20-20kHz: +/-0.09dB
• Dynamic range: 107.5dB typical (A-weighted)
• THD+N @ 1kHz: -101dB typical (un-weighted)
Phones
• Output impedance: 10Ω
• Maximum output level: +11.4dBu
• Frequency response 20-20kHz: +/-0.09dB
• Dynamic range: 104dB typical (A-weighted)
• Power @ 33ohm: 137mW
Supported Sample rates
• 44.1kHz, • 48kHz, • 88.2 kHz,
• 96kHz, • 176.4kHz, • 192 kHz
Description
Arturia MiniFuse 4
Record your song, record your story, record you - record anything. MiniFuse 4 is a next-gen 4in/4out audio & MIDI interface designed to transform your ideas into your art. Capture crystal-clear recordings, refine with pro-grade creative software, and get your sound out there.
You need great sound and a great workflow to make your creativity happen. MiniFuse 4 is an evolved audio interface designed to take you there.
For bands, producers, performers, podcasters, and everyone in between; enjoy best-in-class sound quality, an innovative feature set, and the best software included as standard. MiniFuse 4 ticks all the boxes - what’s stopping you?
MiniFuse 4’s connections, features, and unique innovations are designed to make your creative life easier.
From careful selection of components through to manufacture & testing, the MiniFuse range is engineered to last.
Each interface is constructed with the most robust & reliable materials, and goes through over 200 reliability tests before approval, meaning better build quality, a better product for the environment, and better value for you.
Unmatched Sound Quality
Line Inputs
• Input impedance: 16kΩ
• Maximum input level: +22dBu
• Gain range: 56dB
• Frequency response 20Hz to 20kHz: +/-0.05dB (min gain)
• Dynamic range: 110dB typical (A-weighted)
• THD+N @ 1kHz: -100dB typical (un-weighted)
Instrument Input
• Input impedance: 1MΩ on Tip
• Maximum input level: +11.5dBu
• Gain range: 56dB
• Frequency response 20Hz to 20kHz: +/-0.06dB (min gain)
• Dynamic range: 110dB typical (A-weighted)
• THD+N @ 1kHz: -91dB typical (un-weighted)
Microphone Preamps
• Input impedance: 2.5kΩ
• Maximum input level: +9dBu
• Gain range: 56dB
• Equivalent Input Noise (EIN): -129dB typical (A-weighted)
• Frequency response 20Hz to 20kHz: +/-0.06dB (min gain)
• Dynamic range: 110dB typical (A-weighted)
• THD+N @ 1kHz: -100dB typical (un-weighted)
Speakers
• Output impedance: 94Ω
• Maximum output level: +12dBu
• Frequency response 20-20kHz: +/-0.09dB
• Dynamic range: 107.5dB typical (A-weighted)
• THD+N @ 1kHz: -101dB typical (un-weighted)
Phones
• Output impedance: 10Ω
• Maximum output level: +11.4dBu
• Frequency response 20-20kHz: +/-0.09dB
• Dynamic range: 104dB typical (A-weighted)
• Power @ 33ohm: 137mW
Supported Sample rates
• 44.1kHz, • 48kHz, • 88.2 kHz,
• 96kHz, • 176.4kHz, • 192 kHz
